DRW Thermal Cutting Bag Making Machine
DRW Thermal Cutting Bag Making Machine — widths 10–950 mm, output 40–180 pcs/min, factory-direct $15,000 – $60,000. Micro-computer controlled bag maker for BOPP, OPP and PE film — sock bags, towel bags, bread bags and ornament bags with photocell registration and auto counting.
Watch it run
Real production video of the drw thermal cutting bag making machine in our Wenzhou plant.
DRW Bag Making Machine — Factory Footage
- Machine running in real production
- Key process steps visible
- Finishing and winding shown
- Factory environment — not a studio render
Technical specifications
Complete technical parameters for the drw thermal cutting bag making machine series.
| Model | DRW-600 | DRW-700 | DRW-800 | DRW-900 | DRW-1000 |
|---|---|
| Bag Width | 10–550 mm | 10–650 mm | 10–750 mm | 10–850 mm | 10–950 mm |
| Bag Length | 50–990 mm |
| Bag Thickness | 0.01–0.10 mm |
| Bag Speed | 40–180 pcs/min |
| Total Power | 3.0 kW | 3.6 kW | 3.8 kW | 4.5 kW | 4.7 kW |
| Machine Weight | 800 kg | 900 kg | 1,000 kg | 1,100 kg | 1,200 kg |
| Overall Dimension (L×W×H) | 3.3 × 1.0 × 1.7 m | 3.3 × 1.1 × 1.7 m | 3.3 × 1.2 × 1.7 m | 3.3 × 1.3 × 1.7 m | 3.3 × 1.4 × 1.7 m |
| Materials | BOPP · OPP · PE — printed or non-printed film |
Key features
Standard: Micro-computer control · stepper motor draw (servo optional) · step-length photocell registration · auto stop on lost label · automatic double-sided sticky tape device · auto-puncher · auto-counter · regulated-temperature thermal sealing
Optional: Triangle folding device
Optional: EPC edge guide with automatic tension control
Optional: Ultrasonic unit
Optional: Top film gusset device
Optional: D-cut handle bag punching device
- Optional: Color photocell (German-made) for printed film registration
- Optional: Reversible sealing blade for longer service life
- Key components: Shanghai main motor with auto-shutdown
- Key components: AC unwind and rewind motors (Shanghai)
- Key components: Huihuang computer controller; LONGYOU photocell; China-made inverter
- Key components: CHINT electric appliances
- Key components: Flower knife and flat knife made in-house
- Key components: Shenzhen-made punchers; joint-venture conveyor; China-made temperature controller
What it produces
Products you can manufacture with the drw thermal cutting bag making machine.
